LOOKUP JOIN

The ES|QL LOOKUP JOIN processing command combines data from your ES|QL query results table with matching records from a specified lookup index. It adds fields from the lookup index as new columns to your results table based on matching values in the join field.

Teams often have data scattered across multiple indices – like logs, IPs, user IDs, hosts, employees etc. Without a direct way to enrich or correlate each event with reference data, root-cause analysis, security checks, and operational insights become time-consuming.

For example, you can use LOOKUP JOIN to:

• Retrieve environment or ownership details for each host to correlate your metrics data.
• Quickly see if any source IPs match known malicious addresses.
• Tag logs with the owning team or escalation info for faster triage and incident response.

LOOKUP JOIN is similar to ENRICH in the fact that they both help you join data together. You should use LOOKUP JOIN when:

• Your enrichment data changes frequently
• You want to avoid index-time processing
• You want SQL-like behavior, so that multiple matches result in multiple rows
• You need to match on any field in a lookup index
• You use document or field level security
• You want to restrict users to use only specific lookup indices
• You do not need to match using ranges or spatial relations

The LOOKUP JOIN command adds fields from the lookup index as new columns to your results table based on matching values in the join field.

The command requires two parameters:

• The name of the lookup index (which must have the lookup index.mode setting)
• The name of the field to join on

LOOKUP JOIN <lookup_index> ON <field_name>

×

If you're familiar with SQL, LOOKUP JOIN has left-join behavior. This means that if no rows match in the lookup index, the incoming row is retained and nulls are added. If many rows in the lookup index match, LOOKUP JOIN adds one row per match.

You can run this example for yourself if you'd like to see how it works, by setting up the indices and adding sample data.

 PUT threat_list {
  "settings": {
    "index.mode": "lookup"
  },
  "mappings": {
    "properties": {
      "source.ip": { "type": "ip" },
      "threat_level": { "type": "keyword" },
      "threat_type": { "type": "keyword" },
      "last_updated": { "type": "date" }
    }
  }
}

 PUT firewall_logs {
  "mappings": {
    "properties": {
      "timestamp": { "type": "date" },
      "source.ip": { "type": "ip" },
      "destination.ip": { "type": "ip" },
      "action": { "type": "keyword" },
      "bytes_transferred": { "type": "long" }
    }
  }
}

 POST threat_list/_bulk {"index":{}}
{"source.ip":"203.0.113.5","threat_level":"high","threat_type":"C2_SERVER","last_updated":"2025-04-22"}
{"index":{}}
{"source.ip":"198.51.100.2","threat_level":"medium","threat_type":"SCANNER","last_updated":"2025-04-23"}

 POST firewall_logs/_bulk {"index":{}}
{"timestamp":"2025-04-23T10:00:01Z","source.ip":"192.0.2.1","destination.ip":"10.0.0.100","action":"allow","bytes_transferred":1024}
{"index":{}}
{"timestamp":"2025-04-23T10:00:05Z","source.ip":"203.0.113.5","destination.ip":"10.0.0.55","action":"allow","bytes_transferred":2048}
{"index":{}}
{"timestamp":"2025-04-23T10:00:08Z","source.ip":"198.51.100.2","destination.ip":"10.0.0.200","action":"block","bytes_transferred":0}
{"index":{}}
{"timestamp":"2025-04-23T10:00:15Z","source.ip":"203.0.113.5","destination.ip":"10.0.0.44","action":"allow","bytes_transferred":4096}
{"index":{}}
{"timestamp":"2025-04-23T10:00:30Z","source.ip":"192.0.2.1","destination.ip":"10.0.0.100","action":"allow","bytes_transferred":512}

FROM firewall_logs
| LOOKUP JOIN threat_list ON source.ip
| WHERE threat_level IS NOT NULL
| SORT timestamp
| KEEP timestamp, source.ip, destination.ip, action, threat_level, threat_type
| LIMIT 10

1. The source index
2. The lookup index and join field
3. Filter for rows non-null threat levels
4. LOOKUP JOIN does not guarantee output order, so you must explicitly sort the results if needed
5. Keep only relevant fields
6. Limit the output to 10 rows

A successful query will output a table. In this example, you can see that the source.ip field from the firewall_logs index is matched with the source.ip field in the threat_list index, and the corresponding threat_level and threat_type fields are added to the output.

   source.ip   |    action     |  threat_type  | threat_level
---------------+---------------+---------------+---------------
203.0.113.5    |allow          |C2_SERVER      |high
198.51.100.2   |block          |SCANNER        |medium
203.0.113.5    |allow          |C2_SERVER      |high

Refer to the examples section of the LOOKUP JOIN command reference for more examples.

To use LOOKUP JOIN, the following requirements must be met:

• Indices used for lookups must be configured with the lookup index mode
• Compatible data types: The join key and join field in the lookup index must have compatible data types. This means:
  • The data types must either be identical or be internally represented as the same type in ES|QL
  • Numeric types follow these compatibility rules:
    • short and byte are compatible with integer (all represented as int)
    • float, half_float, and scaled_float are compatible with double (all represented as double)
  • For text fields: You can only use text fields as the join key on the left-hand side of the join and only if they have a .keyword subfield

To obtain a join key with a compatible type, use a conversion function if needed.

For a complete list of supported data types and their internal representations, see the Supported Field Types documentation.

The following are the current limitations with LOOKUP JOIN

• Indices in lookup mode are always single-sharded.
• Cross cluster search is unsupported initially. Both source and lookup indices must be local.
• Currently, only matching on equality is supported.
• LOOKUP JOIN can only use a single match field and a single index. Wildcards, aliases, datemath, and datastreams are not supported.
• The name of the match field in LOOKUP JOIN lu_idx ON match_field must match an existing field in the query. This may require RENAMEs or EVALs to achieve.
• The query will circuit break if there are too many matching documents in the lookup index, or if the documents are too large. More precisely, LOOKUP JOIN works in batches of, normally, about 10,000 rows; a large amount of heap space is needed if the matching documents from the lookup index for a batch are multiple megabytes or larger. This is roughly the same as for ENRICH.
